ALFA-LAVAL PUMP OEM SEALS
We manufacture and stock many mechanical seals, both ZMT engineered and O.E.M. replicated, for many sanitary centrifugal and positive displacement pumps.
ZM Technologies manufactures all of our O.E.M. replica seals to meet or exceed original specifications. These seals are interchangeable with the original and will perform as good as or better than the O.E.M.
The ZMT Alfa-Laval LKH & CL O.E.M replicated seals are made to fit a wide range of Alfa-Laval pumps:
- All 35mm & 42mm LKH Seals, Models 5 thru 110.
- All ALC pumps, 40mm, 53mm & 60mm Seals, Models 1 thru 3.
- All CL 31.75mm Single & Double Seals.
All seals are available in a wide range of seal face & O-ring materials.
Contact the factory regarding how ZMT engineered seals can be used in your application.
All seals carry a satisfaction guarantee. See Policy page for details.
| SEAL LIST – Alfa Laval LKH 5-60 Centrifugal Pump | |||
|---|---|---|---|
| Description | Material | Ref. Part No. | ZMT Part No. |
| Single Seal Assembly, 1.250″ (31.7 mm) | CBN/SiC/EPDM | 9612-1296-09 | ALKH1250-00-5200E |
| Single Seal Assembly, 1.250″ (31.7 mm) | CBN/SiC/Buna | 9612-1296-10 | ALKH1250-00-5200B |
| Single Seal Assembly, 1.250″ (31.7 mm) | CBN/SiC/Viton® | 9612-1296-11 | ALKH1250-00-5200V |
| Single Seal Assembly, 1.250″ (31.7 mm) | SiC/SiC/EPDM | 9612-1296-05 | ALKH1250-00-2200E |
| Single Seal Assembly, 1.250″ (31.7 mm) | SiC/SiC/Buna | 9612-1296-06 | ALKH1250-00-2200B |
| Single Seal Assembly, 1.250″ (31.7 mm) | SiC/SiC/Viton® | 9612-1296-07 | ALKH1250-00-2200V |
| Double Seal Assembly, 1.250″ (31.7 mm) | CBN/SiC/EPDM-CBN/SiC/EPDM | 9612-1296-13 | ALKH1250-00-5252E |
| Double Seal Assembly, 1.250″ (31.7 mm) | CBN/SiC/Buna-CBN/SiC/Buna | 9612-1296-14 | ALKH1250-00-5252B |
| Double Seal Assembly, 1.250″ (31.7 mm) | CBN/SiC/Viton®-CBN/SiC/Viton® | 9612-1296-15 | ALKH1250-00-5252V |
| Double Seal Assembly, 1.250″ (31.7 mm) | SiC/SiC/EPDM-SiC/SiC/EPDM | 9612-1296-17 | ALKH1250-00-2222E |
| Double Seal Assembly, 1.250″ (31.7 mm) | SiC/SiC/Buna-SiC/SiC/Buna | 9612-1296-18 | ALKH1250-00-2222B |
| Double Seal Assembly, 1.250″ (31.7 mm) | SiC/SiC/Viton®-SiC/SiC/Viton® | 9612-1296-19 | ALKH1250-00-2222V |
| SEAL LIST – Alfa Laval LKH 70-80 Centrifugal Pump | |||
|---|---|---|---|
| Description | Material | Ref. Part No. | ZMT Part No. |
| Single Seal Assembly, 42mm | SiC/CBN/EPDM | 9612-5151-01 | ALKH042-00-5200E |
| Single Seal Assembly, 42mm | SiC/CBN/Buna | 9612-5151-02 | ALKH042-00-5200B |
| Single Seal Assembly, 42mm | SiC/CBN/Viton® | 9612-5151-03 | ALKH042-00-5200V |
| Single Seal Assembly, 42mm | SiC/SiC/EPDM | 9612-5151-05 | ALKH042-00-2200E |
| Single Seal Assembly, 42mm | SiC/SiC/Buna | 9612-5151-06 | ALKH042-00-2200B |
| Single Seal Assembly, 42mm | SiC/SiC/Viton® | 9612-5151-07 | ALKH042-00-2200V |
| SEAL LIST – Alfa Laval LKH 110-120 Multi-Stage Centrifugal Pump | |||
|---|---|---|---|
| Description | Material | Ref. Part No. | ZMT Part No. |
| Single Seal Assembly, Non-Flushed 32 mm | SiC/CBN/EPDM | 9612-3622-01 | ALKH032P-00-5200E |
| Single Seal Assembly, Non-Flushed 32 mm | SiC/CBN/Buna | 9612-3622-02 | ALKH032P-00-5200B |
| Single Seal Assembly, Non-Flushed 32 mm | SiC/CBN/Viton® | 9612-3622-03 | ALKH032P-00-5200V |
| Single Seal Assembly, Non-Flushed 32 mm | SiC/SiC/EPDM | 9612-3622-04 | ALKH032P-00-2200E |
| Single Seal Assembly, Non-Flushed 32 mm | SiC/SiC/Buna | 9612-3622-05 | ALKH032P-00-2200B |
| Single Seal Assembly, Non-Flushed 32 mm | SiC/SiC/Viton® | 9612-3622-06 | ALKH032P-00-2200V |
| SEAL LIST – Alfa Laval CL Centrifugal Pump (also for Tri-Clover® CL) | |||
|---|---|---|---|
| Description | Material | Ref. No. | ZMT Part No. |
| Single Mechanical Seal Assembly, 32 mm | CBN/SiC/EPDM | 9612-7118-01 | TCL2264-00-5200E |
| Single Mechanical Seal Assembly, 32 mm | CBN/SiC/Buna | 9612-7118-02 | TCL2264-00-5200B |
| Single Mechanical Seal Assembly, 32 mm | CBN/SiC/Viton® | 9612-7118-03 | TCL2264-00-5200V |
| Single Mechanical Seal Assembly, 32 mm | SiC/SiC/EPDM | 9612-7119-01 | TCL2264-00-2200E |
| Single Mechanical Seal Assembly, 32 mm | SiC/SiC/Buna | 9612-7119-02 | TCL2264-00-2200B |
| Single Mechanical Seal Assembly, 32 mm | SiC/SiC/Viton® | 9612-7119-03 | TCL2264-00-2200V |
Alfa-Laval (G&H) Pump Hyclean OEM Seals
ZM Technologies manufactures all of our O.E.M. replica seals to meet or exceed original specifications. These seals are interchangeable with the original and will perform as good as or better than the O.E.M.
The ZMT Alfa-Laval (G&H) O.E.M replicated seal is made to fit the Alfa-Laval (G&H) PD pumps:
- All TSE/SRE pump model seals, models 1 (322/332) thru Model 6 (822/832).
All seals are available in a wide range of seal face & o-ring materials.
Contact the factory regarding how ZMT engineered seals can be used in your application.
All seals carry a satisfaction guarantee. See Policy page for details.
- SRU Model 1 (TSE 322/332) Seals
- SRU Model 2 (TSE 422/432) Seals
- SRU Model 3 (TSE 522/532) Seals
- SRU Model 4 (TSE 622/632) Seals
- SRU Model 5 (TSE 722/732) Seals
- SRU Model 6 (TSE 822/832) Seals
| SEAL LIST – Alfa Laval (G&H) TSE/SRU 1 (322 & 332) PD Pump | |||
|---|---|---|---|
| Description | Material | Reference Part No. | ZMT Part No. |
| 20mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/EPDM | 9630053608 | GH322-00-1500E |
| 20mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Buna | 9630070142 | GH322-00-1500B |
| 20mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Viton® | 9630060999 | GH322-00-1500V |
| 20mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/EPDM | 9630090686 | GH322-00-2500E |
| 20mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Buna | 9630090687 | GH322-00-2500B |
| 20mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Viton® | 9630057357 | GH322-00-2500V |
| 20mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/EPDM | 9630053609 | GH322-00-2200E |
| 20mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Buna | 9630090685 | GH322-00-2200B |
| 20mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Viton® | 9630065312 | GH322-00-2200V |
| SEAL LIST – Alfa Laval (G&H) TSE/SRU 2 (422 & 432) PD Pump | |||
|---|---|---|---|
| Description | Material | Reference Part No. | ZMT Part No. |
| 30mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/EPDM | 9630046731 | GH422-00-1500E |
| 30mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Buna | 9630046729 | GH422-00-1500B |
| 30mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Viton® | 9630046730 | GH422-00-1500V |
| 30mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/EPDM | 9630046747 | GH422-00-2500E |
| 30mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Buna | 9630046745 | GH422-00-2500B |
| 30mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Viton® | 9630046746 | GH422-00-2500V |
| 30mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/EPDM | 9630046760 | GH422-00-2200E |
| 30mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Buna | 9630046758 | GH422-00-2200B |
| 30mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Viton® | 9630046759 | GH422-00-2200V |
| SEAL LIST – Alfa Laval (G&H) TSE/SRU 3 (522 & 532) PD Pump | |||
|---|---|---|---|
| Description | Material | Ref. Part No. | ZMT Part No. |
| 35mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/EPDM | 9630046735 | GH522-00-1500E |
| 35mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Buna | 9630046733 | GH522-00-1500B |
| 35mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Viton® | 9630046734 | GH522-00-1500V |
| 35mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/EPDM | 9630046751 | GH522-00-2500E |
| 35mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Buna | 9630046749 | GH522-00-2500B |
| 35mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Viton® | 9630046750 | GH522-00-2500V |
| 35mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/EPDM | 9630046763 | GH522-00-2200E |
| 35mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Buna | 9630046761 | GH522-00-2200B |
| 35mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Viton® | 9630046762 | GH522-00-2200V |
| SEAL LIST – Alfa Laval (G&H) TSE/SRU 4 (622 & 632) PD Pump | |||
|---|---|---|---|
| Description | Material | Ref. Part No. | ZMT Part No. |
| 45mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/EPDM | 9630046741 | GH622-00-1500E |
| 45mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Buna | 9630046737 | GH622-00-1500B |
| 45mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Viton® | 9630046740 | GH622-00-1500V |
| 45mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/EPDM | 9630046754 | GH622-00-2500E |
| 45mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Buna | 9630046752 | GH622-00-2500B |
| 45mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Viton® | 9630046753 | GH622-00-2500V |
| 45mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/EPDM | 9630046767 | GH622-00-2200E |
| 45mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Buna | 9630046765 | GH622-00-2200B |
| 45mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Viton® | 9630046766 | GH622-00-2200V |
| SEAL LIST – Alfa Laval (G&H) TSE/SRU 5 (722 & 732) PD Pump | |||
|---|---|---|---|
| Description | Material | Ref. Part No. | ZMT Part No. |
| 55mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/EPDM | 9630046744 | GH722-00-1500E |
| 55mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Buna | 9630046738 | GH722-00-1500B |
| 55mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Viton® | 9630046743 | GH722-00-1500V |
| 55mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/EPDM | 9630046757 | GH722-00-2500E |
| 55mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Buna | 9630046755 | GH722-00-2500B |
| 55mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Viton® | 9630046756 | GH722-00-2500V |
| 55mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/EPDM | 9630046771 | GH722-00-2200E |
| 55mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Buna | 9630046769 | GH722-00-2200B |
| 55mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Viton® | 9630046770 | GH722-00-2200V |
| SEAL LIST – Alfa Laval (G&H) TSE/SRU 6 (822 & 832) PD Pump | |||
|---|---|---|---|
| Description | Material | Ref. Part No. | ZMT Part No. |
| 67mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/EPDM | 9630041719 | GH822-00-1500E |
| 67mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Buna | 9630053215 | GH822-00-1500B |
| 67mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SS/Viton® | 9630030780 | GH822-00-1500V |
| 67mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/EPDM | 9630041729 | GH822-00-2500E |
| 67mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Buna | 9630090689 | GH822-00-2500B |
| 67mm G&H PD Seal Kit, Hyclean Single non-flushed | CBN/SiC/Viton® | 9630057267 | GH822-00-2500V |
| 67mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/EPDM | 9630041720 | GH822-00-2200E |
| 67mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Buna | 9630060539 | GH822-00-2200B |
| 67mm G&H PD Seal Kit, Hyclean Single non-flushed | SiC/SiC/Viton® | 9630049360 | GH822-00-2200V |
